Description

NOHRD SlimBeam Cable Machine

The NOHRD SlimBeam is a compact cable training machine with an integrated weight stack, dual cable pulley system, and height-adjustable butterfly arms for full-body strength training.

Designed for home gyms, studios, and premium training spaces, the SlimBeam delivers smooth resistance, quiet operation, and a space-saving footprint with its genuine wood veneer casing and wall-mounted design.

Key Features

• Compact cable machine design supports full-body strength training in minimal floor space
• Height-adjustable butterfly arms allow unilateral, bilateral, horizontal, diagonal, high-to-low, and low-to-high cable movements
• Ball-bearing cable rollers create smooth, quiet, and consistent pulley movement
• 75 kg integrated weight stack uses 15 x 5 kg weight plates for precise resistance adjustment
• Rubberized weight plates help reduce noise during workouts
• Standard 3:1 cable ratio provides fine resistance gradation and up to 8 m cable range
• Integrated solid wood pull-up bar is height adjustable and can be converted into a lat pull-down station with the appropriate accessory
• Optional SlimBeam Monitor upgrade tracks metrics such as selected weight, total lifted weight, and repetitions
• Handmade in Germany with premium wood and metal construction

Exercises

The SlimBeam supports cable strength training for the chest, back, shoulders, arms, legs, core, and glutes. It can be used for functional training, resistance exercises, rehabilitation-style movements, pull-downs, rows, presses, rotations, curls, extensions, and full-body cable workouts.

Who This Is For

This cable machine is ideal for home gym owners, personal trainers, physiotherapists, fitness studios, hotel gyms, and commercial wellness spaces that need a compact, design-focused strength training system with versatile exercise options.

Specifications

• Application: Cable strength training and functional resistance training
• Exercise Focus: Full body, chest, back, shoulders, arms, legs, glutes, and core
• Type: Wall-mounted cable machine with integrated weight stack
• Dimensions: 20 cm x 40 cm x 215 cm
• Product Weight: 120 kg
• Maximum User Weight: 100 kg
• Weight Stack: 75 kg
• Weight Plates: 15 x 5 kg
• Standard Cable Ratio: 3:1
• Optional Cable Ratios: 2:1 and 1:1 cables available
• Single Extension Resistance: 0.83 to 12.50 kg with 3:1 ratio, 1.25 to 18.75 kg with 2:1 ratio, 2.50 to 37.50 kg with 1:1 ratio
• Double Extension Resistance: 1.65 to 25.00 kg with 3:1 ratio, 2.50 to 37.50 kg with 2:1 ratio, 5.00 to 75.00 kg with 1:1 ratio
• Cable Range: Up to 8 m with standard 3:1 cable ratio
• Distance to Wall: 10 cm
• Assembly Required: Yes
• Bluetooth: No
• Power Connection: No
• Country of Manufacture: Germany
• Training Category: Strength
• Packages: 4
• Package 1: 222.5 cm x 51.0 cm x 32.0 cm, 37.5 kg
• Package 2: 63.5 cm x 47.0 cm x 24.0 cm, 25.0 kg
• Package 3: 27.7 cm x 23.7 cm x 16.4 cm, 36.0 kg
• Package 4: 27.7 cm x 23.7 cm x 16.4 cm, 36.0 kg
• Included with Delivery: Pull-up bar with adapter, cords, and assembly instructions
• Optional Upgrade: SlimBeam Monitor
• Shipping Method: Standard

Warranty

The product details list a 2 year warranty. NOHRD warranty terms state that NOHRD labeled products are covered for 1 year from initial shipment against defects in material or workmanship and can be upgraded to 2 years on all components and wooden components when registered within the first year of purchase.

Frequently Asked Questions

Is the NOHRD SlimBeam suitable for small spaces?
Yes. The SlimBeam has a compact footprint, mounts close to the wall, and measures only 20 cm x 40 cm x 215 cm.

How much resistance does the SlimBeam provide?
The SlimBeam has a 75 kg integrated weight stack with 15 x 5 kg plates. The standard 3:1 cable ratio provides up to 12.50 kg on a single extension and up to 25.00 kg on a double extension.

Can both sides of the body be trained independently?
Yes. The adjustable butterfly system allows unilateral and bilateral cable exercises, making it useful for balanced strength training and functional movement work.

Does the SlimBeam require electricity?
No. The SlimBeam itself does not require a power connection. A power connection is required only when using the optional SlimBeam Monitor.

Resources

SlimBeam Assembly Manual
SlimBeam Training Manual
SlimBeam Training and Exercise Guide
NOHRD Warranty Information
